Description
Sensible spending, maximum sending – the Alpine Trail E1 has its priorities sorted. It has a featherweight Series 4 Aluminum frame, ride-all-day 800Wh removable battery and 2in color Kiox top tube display. Experience superhuman climbing power of Bosch’s 120Nm, 600 per cent assist Gen 5 CX motor. Cha-ching! Personalize your ride and devour chunky terrain with adjustable geometry, while 160mm of MultiTrac 2 LT suspension keeps you flowing. X-Fusion’s Vengeance fork and H3A shock are silky performers. Shimano’s CUES drivetrain shifts under pressure, and TRP’s DHR EVO Comp brakes replace question marks with confidence. Premium platform, smart price.
Specification
| Frame | All New Series 4 Alloy for Gen 5 CX Drive Unit, 160mm MultiTrac LT Suspension, Adjustable Headset & CS Length/Height, Integrated Battery/Charging Port, 148mm Rear Thru-Axle |
|---|---|
| Rear Suspension | X-Fusion H3A Air, 205×65, 30xM8 Lower Hardware, Custom Tune |
| Fork | X-Funsion Vengence, 170mm Travel, 44mm Offset, 110x15mm Bolt-on Axle |
| Headset | FSA Custom Headset, Adjustable HTA Design |
| Stem | Marin 3D Forged Alloy, 35mm Length, 35mm Bar Bore |
| Handlebar | Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 30mm Rise, 5" Up, 9" Back |
| Grips | Marin Grizzly Lock-On |
| Brake Levers | TRP DHR EVO Comp |
| Brakes Front | TRP DHR EVO Comp, 200mm Rotors |
| Brakes Rear | TRP DHR EVO Comp, 200mm Rotors |
| Tires | Front: Schwalbe Magic Mary, Gravity Pro, Ultra Soft, Radial, 29×2.5" Rear: Schwalbe Magic Mary, Gravity Pro, Soft, Radial, 27.5×2.5" |
| Rim | New Marin, Double Wall Alloy, 29mm Inner, Sleeved Joint, Disc Specific, 32H, Tubeless Compatible |
| Hub Front | Shimano HF-MT500B, 110x15mm, Centerlock |
| Hub Rear | Shimano HB-MT501B, 148x12mm, Centerlock, STD Freehub Body |
| Spokes | 14g Black Stainless Steel |
| Derailleur Rear | Shimano CUES RD-U6000 GS, 10-Speed |
| Shift Lever | Shimano CUES SL-U6000-10R, 10-Speed |
| Chain | KMC E-Glide |
| Cassette | Shimano CS-LG300-10, 11-48T |
| Crankset | Marin Forged eMTB Cranks, 150mm |
| Saddle | Marin Short Nose |
| Seatpost | TranzX YS160QL Adjustable Travel Dropper Post, Size S=150, M=170mm Travel, Size L-XL 200mm Travel, 34.9mm |
| Motor | Bosch Performance Line CX, 750W, 120Nm |
| Battery | PT800 Horizontal |
| Switch | Bosch BRC3300 Bluetooth Remote 22.2mm Clamp |
| Display | Bosch Kiox 400 Top Tube Display |
| Extra1 | e*thirteen e*Spec Chainguide |
| Extra2 | Bolt-On 12mm Thru-Axle, 174mm Length, 1.0 Thread Pitch, 16.5mm, Tapered Head |
| Extra3 | Bosch 4A |
| Range | 115-55 miles/25-90km |
| Charge Time | 6 hours |
| App | Bosch eBike Flow App |
